Model: YPO-072 YPO-270 YPO-480 YPO-600 YPO-720 YPO-1000
Main Parameters:
Temperature range: RT+25℃～200℃/300℃/400℃(other temps are optional)
Temperature fluctuation: ±0.3℃
Temperature uniformity: ±1％℃(200℃)/±2％℃(300℃)
Heat-up time depends on the size and temperature
Used for product drying, curing and high-temperature aging test. Mainly be applied in chemical, electronic communication, plastics, cable, electroplating, hardware, automotive, photoelectron, rubber products, molds, painting, printing, medical, aerospace and higher education industries.
| Model No. | YPO-072 | YPO-270 | YPO-480 | YPO-600 | YPO-720 | YPO-1000 |
| Internal chamber size (W×H×Dcm) | 40×45×40 | 60×90×50 | 80×100×60 | 100×100×60 | 100×120×60 | 100×100×100 |
| External chamber size (W×H×Dcm) | 72×116×56 | 93×163×67 | 110×172×77 | 130×172×77 | 116×170×116 | 116×150×166 |
| Temperature range | Room temperature +25℃～200℃（300℃） | |||||
| Temperature fluctuation | ±0.3℃ | |||||
| Temperature uniformity | ±1%℃ | |||||
| Temperature resolution | 0.1℃ | |||||
| Heating up time | 30 minutes | |||||
| External chamber material | Cold-rolled sheet + Powder coating | |||||
| Interior chamber material | SUS#201 stainless steel plate (Adopt SUS#304 stainless steel when temperature>200℃) | |||||
| Insulation | fiberglass wool | |||||
| Wind circulation system | Centrifugal fan air circulation system | |||||
| Heating system | Stainless steel high-speed heater | |||||
| Control system | Button type Digital controller | |||||
| Components | Control status indicator, loading shelf(2 pcs, height adjustable) | |||||
| Safe device | Phase Sequence protection, overtemperature, overcurrent, overload protection | |||||
| Power supply | AC 1Ψ 220V 60/50Hz, AC 3Ψ 380V 60/50Hz | |||||
| Customization service | Non-standard or special requirements can be customized. | |||||
Digital display controller or touch screen controller.
Heating method is by hot air circulation, which ensures rapid temperature rise and uniform temperature distribution.
Temperature range can be customized up to 500℃.
Drying and Curing Processes: Precision hot air ovens are extensively used for drying and curing applications in industries such as pharmaceuticals, food processing, and electronics manufacturing. They provide controlled heat distribution, ensuring efficient drying of coatings, powders, and components without compromising product quality.
Heat Treatment: The industrial hot air oven is essential for heat treatment processes where precise temperature control is critical. It is used for annealing, tempering, and stress relieving of metals and alloys in automotive, aerospace, and metallurgical industries. The uniform heating capability ensures consistent results and improves material properties.
Sterilization: In medical and laboratory settings, the precision hot wind oven is used for sterilizing equipment, glassware, and instruments. The controlled heat ensures thorough sterilization without the use of harmful chemicals, making it ideal for maintaining hygiene and safety standards.
Aging and Testing: Industries involved in research, quality control, and product testing utilize hot air ovens for aging and stability testing of materials and products. The hot wind oven provides stable and repeatable conditions over extended periods, allowing for reliable evaluation of product performance, durability, and shelf-life.
